Simucube 3 Ultimate is a direct drive force feedback wheelbase that raises performance to an entirely new level, with demands so high it required a completely new type of motor. Featuring an advanced direct drive optimized IPM motor and it offers 35 Nm of torque with maximum response speed, all while using less power. Professional-grade performance, taken to the next level.
- Precise, smooth, industry-leading direct drive force feedback (35 Nm)
- Industrial-grade servo motors engineered exclusively for Simucube
- Enhanced detail – telemetry‑based effects like ABS, RPM, and road texture
- Completely re-engineered the control algorithm for maximum accuracy and silent performance
- Frictionless setup – front & bottom mounting, versatile adapters
If you want to use more than one Simucube Link Hub device such Simucube 3 and ActivePedals, please purchase the Teltonika Ethernet Switch.
Dimensions
- Wheel base dimensions: 135 x 135 x 323 mm
- Package dimensions: 190 x 300 x 390 mm
- Mounting: Front and Bottom
- Mounting hole pattern DIA: 135 mm and 78,4 mm
- Flange centering feature DIA: 110 mm
- Wheel base weight: 13 kg
Specifications
- Motor type: IPM motor. Maximum response speed. Direct drive optimized IPM motor
- Max torque: 35 Nm
- Angle sensor: 23-bit absolute (8 000 000 steps)
- Power supply: 360 W (450 W peak)
- Warranty: 5 years
What’s Included
- 1x Simucube 3 Ultimate wheelbase
- 1x Power adapter
- 1x RJ45 Cable
- 1x AC power cord
- 1x Quick Start Guide
- 1x Control box
Fasteners kit
- 4x M8 washer
- 4x M6 washer
- 2x M5 washer
- 4x M8x35 allen head bolt
- 4x M8x30 allen head bolt
- 2x M5x30 allen head bolt
- 4x M6x16 allen head bolt
- 2x M5 t-slot nut 8mm slot
Does NOT include: Link Quick Release for Simucube 3, Simucube Link Hub
